EOS Zeus HD series

floor-standing, heavy-duty

Designer, luxury class sauna heater.

Exclusive premium floor-standing model is ideal for very intensive commercial operation of the Finnish sauna. The highlight of this model is the round case in a reinforced steel construction with impressive ~100 kg rock store.

"Heavy-duty" version with the internal wiring as massive copper rails. Copper rails as standard inner wiring make the high-performance heater Zeus HD perfectly suitable for saunas with particulary intensive commercial use.

Very robust, durable construction with massive 8 mm steel wall. Finish – red-brown powder coating in "Rust Marble" (alternatively available in matt black or anthracite pearl effect finish).
Incl. 2 connection cables with special heavy-duty plugs.

The optional round protection rail 360° or 270° sets the crowning touch to the heater’s design.

Models with output capacities of 20 to 24 kW are supplied with safety slots. For the 30 and 36 kW models, an additional stone attachment frame is included in the delivery.

The EOS Zeus L HD variant has an alternative design based on the EOS Zeus HD sauna heater. Ideal for installations in front of glass panels or in the center of the sauna.

Rock store fits approx. 100 kg sauna stones.

EOS Zeus HD

Designer sauna heater with a unique round design for the Finnish (dry) sauna. Rock store fits up to 100 kg stones.

EOS Zeus HD – guard rail optional
EOS Zeus HD
EOS Zeus HD anthracite – guard rail optional
EOS Zeus HD anthracite
EOS Zeus HD with stack frame (included in delivery for models with 30 kW and 36 kW output)

EOS Zeus L HD

Alternative design model based on the EOS Zeus HD sauna heater. Ideal for installations in front of glass panels or in the center of the sauna.

EOS Zeus L HD – guard rail optional
EOS Zeus L HD
EOS Zeus L HD anthracite – guard rail optional
EOS Zeus L HD anthracite
EOS Zeus HD with stack frame (included in delivery for models with 30 kW and 36 kW output)

Your advantages

Designer luxury class sauna heater for saunas up to 75 m³.
Suitable for very intensive commercial operation.
Spectacular round shaped design with red-brown powder coating in "Rust Marble". High precision laser cut housing.
Alternatively available in anthracite pearl effect or black finish.
Optional round shape safety guard rail in matching design. The guard rail is available in different wood sorts and in 270° or 360° design (Ø 940 mm diameter).
Very robust, durable construction with massive 8 mm steel wall.
Includes pre-mounted double-line connection cable with special heavy-duty connectors.
Extra large rock store fits approx. 100 kg stones - for powerful water splashes and temperature stability.

Technical specifications

Electrical connection	400 V 3N ~ 50/60 Hz
Dimensions (W x H)	70 x 125 cm (Zeus) 70 x 79 cm (Zeus L)
Fuse protection control unit)	3 x 16 A / 1 x 16 A (bei 30 und 36 kW)
Min. size of air inlet and outlet (20 - 24 / 30 - 36 kW)	50 x 8 cm ~Ø 25-30 cm / 50 x 10 cm ~Ø 25-30 cm
Weight withouth rocks	~140 kg
Stone filling	~100 kg

Data

Power	Fuse protection LSG unit	for sauna cabin size	Power extension required
20,0 kW	3 x 25 A	24 - 30 m³	PEB 18
24,0 kW	3 x 35 A	35 - 40 m³	PEB 18
30,0 kW	3 x 50 A	50 - 65 m³	PEB 36
36,0 kW	3 x 63 A	65 - 75 m³	PEB 36

Model overview

EOS Zeus HD

Power	Item no.
20,0 kW	947837	red-brown "Rust Marble"
24,0 kW	947838	red-brown "Rust Marble"
30,0 kW	947839	red-brown "Rust Marble"
36,0 kW	947840	red-brown "Rust Marble"
20,0 kW	947841	black
24,0 kW	947842	black
30,0 kW	947843	black
36,0 kW	947844	black
20,0 kW	947854	anthracite
24,0 kW	947846	anthracite
30,0 kW	947847	anthracite
36,0 kW	947848	anthracite

EOS Zeus L HD

Power	Item no.
20,0 kW	947849	red-brown "Rust Marble"
24,0 kW	947850	red-brown "Rust Marble"
30,0 kW	947851	red-brown "Rust Marble"
36,0 kW	947825	red-brown "Rust Marble"
20,0 kW	947853	black
24,0 kW	947854	black
30,0 kW	947855	black
36,0 kW	947856	black
20,0 kW	947857	anthracite
24,0 kW	947858	anthracite
30,0 kW	947859	anthracite
36,0 kW	947860	anthracite
