EOS Thermat series

floor-standing-/wall-mounting

Universal sauna heater for private sauna cabins.

EOS Thermat W features a timeless, elegant design, thanks to its aluminium die-cast top and scratch resistant anthracite pearl effect outer shell.

Wall-mounting or floor-standing model with durable construction for many years of reliable service. Rock store made of stainless steel ensures ideal air convection and high temperature reserves for powerful sauna infusions. Terminal box at the rear.

The Bi-O variant is additionally equipped with an integrated vaporizer on the right side. Includes a holder for herbs and oils. Manual filling (approx. 5 liters). Integrated dry-run protection and acoustic water shortage warning.

Rock store fits up to 15 kg stones.

Model variants

EOS Thermat

Floor-standing model for the Finnish (dry) sauna. Rock store fits up to 15 kg stones.

EOS Thermat W

Wall-mounting model for the Finnish (dry) sauna. Rock store fits up to 15 kg stones.

EOS Bi-O Thermat

Floor-standing model with integrated vaporizer for flexible climate forms. Rock store fits up to 15 kg stones.

EOS Bi-O Thermat W

Wall-mounting model with integrated vaporizer for flexible climate forms. Rock store fits up to 15 kg stones.

Your advantages

Versatile sauna heater for private saunas.
Timeless, contemporary design.
Only 4 cm gaps to flammable materials on the sides.
Elegant die-cast aluminium top.
Scratch resistant anthracite pearl effect powder-coating.
Proven, durable construction with long-life heating elements.
Optimal relation between stone volume and air convection system for fast heat-up times and powerful sauna infusions.
Rock store fits up to 15 kg stones.
EOS Bi-O Thermat / Thermat W:
- Flexible sauna climate settings.
- Vaporizer 1,5 kW with 5 l water tank, manual water filling.
- Dry-run protection with acoustic alarm.
- Essences cupholder at the steam output.

Technical specifications

Electrical connection	400 V 3N ~ 50/60 Hz 400V 3N / 230V 1N universal (Thermat W)
Fuse protection (control unit)	3 x 16 A
Dimensions H/W/D, in cm	76 x 37,5 x 38 (Thermat) 58 x 37,5 x 38 (Thermat W) 76 x 45 x 38 (Bi-O Thermat) 58 x 45 x 38 (Bi-O Thermat W)
For sauna cabin size (4,5 / 6,0 / 7,5 / 9,0 kW)	4 - 6 m³ / 6 - 8 m³ / 7 - 10 m³ / 9 - 14 m³
Min. size of air intake and outlet (4,5 / 6,0 / 7,5 / 9,0 kW)	35 x 3 cm / 35 x 4 cm / 35 x 5 cm / 35 x 6 cm
Stone filling	15 kg
Power extension needed	no
