EOS Herkules S25 series

floor-standing

The EOS Herkules S25 series are elegant, compact-size floor-standing heaters for private and commercials saunas.

Side panels in anthracite pearl effect finish and brushed stainless steel provide a distinctive high contrast, straight-ligned design. Also available with high-quality matt black finish.

Thanks to the flat rear side panel with the recessed terminal block, these heaters may be installed in front of glass panels.

The Bi-O variant is additionally equipped with an integrated vaporizer. Includes a holder for herbs and oils. Manual filling (approx. 5 liters). Integrated dry-run protection with acoustic alarm.

Rock store fits up to 25 kg stones.

Optional: Heater guard rail with mounting brackets, rear wall cover panel.

EOS Herkules S25

Floor-standing model for the Finnish (dry) sauna. Rock store fits up to 25 kg stones.

EOS Herkules S25 black

EOS Herkules S25 Vapor

Floor-standing model with integrated vaporizer for flexible climate forms. Rock store fits up to 25 kg stones..

EOS Herkules S25 Vapor black

Your advantages

Exclusive design with brushed stainless steel front and anthracite pearl effect coated side panels.
Durable, long-lasting construction, all made of stainless steel.
Also available with elegant matt black finish.
Large 25 kg rock store for optimal heat storage and effective water evaporation.
No direct contact between stones and heating elements – for improved air convection and easy service.
Slim, space-saving construction – only 40 x 38,5 cm footprint.
EOS Herkules S25 Vapor:
- Flexible sauna climate settings.
- 2 kW vaporizer with stainless steel water tank. Manual filling.
- Dry-run protection with acoustic alarm.
- Essences cupholder at the steam output.

Technical specifications

Electrical connection	400 V 3N ~ 50/60 Hz
Dimensions H/W/D, in cm	70 / 40 / 38,5 (S25) 75 / 45 / 38,5 (S25 Vapor)
For sauna cabin size (7.5 / 9 kW)	8 - 12 m³ / 10 - 14 m³
Min. size air inlet and outlet (7.5 / 9 kW)	35 x 5 cm / 35 x 6 cm
Fuse protection control unit	3 x 16 A
Weight withouth rocks	25,5 kg
Stone filling	25 kg
Power extension required	no
