EOS Mega S HD

floor-standing, heavy-duty

High-performance sauna heater for themed & event commercial saunas.

The EOS Mega S HD unites modern design with reliable top performance.

Specially designed for themed and event saunas. Due to the copper rails as standard inner wiring, the heater is perfectly suitable for saunas with particulary intensive use.

The high-performance sauna heater has a power range from 36.0 to 48.0 kW.

The extra large rock store with an opulent stone volume of approx. 95 kg is separated from the heating elements and thus ensures optimal air convection and guarantees a long service life for the heating elements. The unique V-shape profiles ensure effective and complete evaporation during the infusion. Fast heat-up times and powerful infusions are guaranteed.


Power

Item no.

36,0 kW

948094

42,0 kW

948045

48,0 kW

948044



  • High power sauna heater with a power range from 36 to 48 kW.
  • Expertly egineered, reinforced construction made of top-quality stainless steel, optimised for intensive commercial use.
  • Optimal relation between stone volume and air convection ability for fast heat-up times and powerful water splashes.
  • Rock store separated from heating elements for stable air flow. With unique EOS-designed V-shape profiles to ensure effective and complete evaporation by intensive water splashes.
  • Contemporary, timesless design with uniform appearance on all sides. No typical “rear side”. Connections at the bottom.
  • Great for position in front of glass or in the centre of the sauna.
  • Rock store volume of up to 95 kg.
  • "Heavy-duty" version with copper rails as standard inner wiring and therefore perfectly suitable for saunas with particulary intensive use.

Electrical connection

400 V 3N ~ 50/60 Hz

Dimensions H/W/D, in cm

100 / 90 / 80

Stone filling

approx. 95 kg

Power extension required (36 / 42-48 kW)

LSG 36 / 1x LSG 18 + 1x LSG 36

Power

For sauna cabin size

Min. size air inlet and outlet

Weight without rocks

36,0 kW

60 - 75 m³

50 x 10 cm

~110 kg

42,0 kW

65 - 80 m³

50 x 12 cm

~111 kg

48,0 kW

70 - 90 m³

60 x 12 cm

~112 kg
